Technical Details

• Package / Case 4-XDFN Exposed Pad
• Output Type Fixed
• Mounting Type Surface Mount
• Current - Output 200mA
• Operating Temperature -40°C ~ 125°C (TJ)
• Output Configuration Positive
• Current - Quiescent (Iq) 50 µA
• Voltage - Input (Max) 5.5V
• Number of Regulators 1
• Supplier Device Package 4-X2SON (1x1)
• Voltage - Output (Min/Fixed) 1V
• Control Features Enable
• PSRR 70dB ~ 50dB (100Hz ~ 1MHz)
• Voltage Dropout (Max) 0.36V @ 150mA
• Protection Features Over Current, Over Temperature, Short Circuit, Reverse Polarity
