Technical Details

• Package / Case 14-SOIC (0.154", 3.90mm Width)
• Mounting Type Surface Mount
• Operating Temperature -55°C ~ 125°C (TA)
• On-State Resistance (Max) 70Ohm
• -3db Bandwidth 200MHz
• Supplier Device Package 14-SOIC
• Voltage - Supply, Single (V+) 2V ~ 10V
• Crosstalk -72dB @ 1MHz
• Switch Circuit SPST - NO
• Multiplexer/Demultiplexer Circuit 1:1
• Channel-to-Channel Matching (ΔRon) 500mOhm
• Channel Capacitance (CS(off), CD(off)) 5pF
• Current - Leakage (IS(off)) (Max) 100nA
• Number of Circuits 4
