Technical Details

• Package / Case 28-SOIC (0.295", 7.50mm Width)
• Output Type Voltage - Buffered
• Mounting Type Surface Mount
• Number of Bits 12
• Data Interface Parallel
• Reference Type External
• Operating Temperature -40°C ~ 85°C
• Voltage - Supply, Analog ±14.25V ~ 15.75V
• Voltage - Supply, Digital 5V
• Settling Time 10µs
• Supplier Device Package 28-SOIC
• Architecture R-2R
• Number of D/A Converters 4
• INL/DNL (LSB) ±1 (Max), ±1 (Max)
• Differential Output No
• DigiKey Programmable Not Verified
