Technical Details

• Package / Case 14-SOIC (0.154", 3.90mm Width)
• Mounting Type Surface Mount
• Logic Type AND Gate
• Operating Temperature -55°C ~ 125°C
• Voltage - Supply 3V ~ 18V
• Current - Output High, Low 8.8mA, 8.8mA
• Number of Inputs 2
• Supplier Device Package 14-SOIC
• Input Logic Level - High 3.5V ~ 11V
• Input Logic Level - Low 1.5V ~ 4V
• Max Propagation Delay @ V, Max CL 100ns @ 15V, 50pF
• Number of Circuits 4
• Current - Quiescent (Max) 1 µA
