- Product Model LTC3789IUFD#TRPBF
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC REG CTRLR BUCK-BOOST 28QFN
- Classification DC DC Switching Controllers
-
PDF
Technical Details
- Package / Case 28-WFQFN Exposed Pad
- Output Type Transistor Driver
- Mounting Type Surface Mount
- Function Step-Up/Step-Down
- Operating Temperature -40°C ~ 125°C (TJ)
- Output Configuration Positive
- Frequency - Switching 200kHz ~ 640kHz
- Topology Buck-Boost
- Voltage - Supply (Vcc/Vdd) 4V ~ 38V
- Supplier Device Package 28-QFN (4x5)
- Synchronous Rectifier Yes
- Control Features Current Limit, Enable, Frequency Control, Power Good, Soft Start
- Output Phases 1
- Duty Cycle (Max) 90%
- Clock Sync No
- Number of Outputs 2
