Technical Details

• Package / Case 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
• Output Type Adjustable
• Mounting Type Surface Mount
• Current - Output 500mA
• Operating Temperature -40°C ~ 125°C
• Output Configuration Positive
• Current - Quiescent (Iq) 105 µA
• Voltage - Input (Max) 5.5V
• Number of Regulators 1
• Supplier Device Package 8-MSOP-EP
• Voltage - Output (Max) 5V
• Voltage - Output (Min/Fixed) 0.8V
• Control Features Enable
• PSRR 60dB (10kHz ~ 100kHz)
• Voltage Dropout (Max) 0.23V @ 500mA
• Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
• Current - Supply (Max) 280 µA
