Technical Details

• Package / Case 10-VFDFN Exposed Pad
• Output Type Adjustable
• Mounting Type Surface Mount
• Current - Output 500mA
• Operating Temperature -40°C ~ 125°C
• Output Configuration Positive
• Voltage - Input (Max) 5.5V
• Number of Regulators 1
• Supplier Device Package 10-VSON (3x3)
• Voltage - Output (Max) 3.6V
• Voltage - Output (Min/Fixed) 0.8V
• Control Features Enable, Power Good, Soft Start
• Grade Automotive
• PSRR 60dB ~ 30dB (1kHz ~ 300kHz)
• Voltage Dropout (Max) 1.39V @ 500mA
• Protection Features Over Current, Over Temperature, Short Circuit, Under Voltage Lockout (UVLO)
• Qualification AEC-Q100
