- Product Model ADG1414BCPZ-REEL7
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC SW SPST-NOX8 11.5OHM 24LFCSP
- Classification Analog Switches, Multiplexers, Demultiplexers
-
PDF
Technical Details
- Package / Case 24-WFQFN Exposed Pad, CSP
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 125°C (TA)
- On-State Resistance (Max) 11.5Ohm
- -3db Bandwidth 256MHz
- Supplier Device Package 24-LFCSP (4x4)
- Voltage - Supply, Single (V+) 12V
- Voltage - Supply, Dual (V±) ±4.5V ~ 16.5V
- Charge Injection 10pC
- Crosstalk -75dB @ 1MHz
- Switch Circuit SPST - NO
- Multiplexer/Demultiplexer Circuit 1:1
- Channel-to-Channel Matching (ΔRon) 550mOhm
- Switch Time (Ton, Toff) (Max) 93ns, 35ns
- Channel Capacitance (CS(off), CD(off)) 8pF
- Current - Leakage (IS(off)) (Max) 150pA
- Number of Circuits 8
