Technical Details

• Package / Case 5-TSSOP, SC-70-5, SOT-353
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 85°C (TA)
• On-State Resistance (Max) 15Ohm
• -3db Bandwidth 330MHz
• Supplier Device Package SC-88A (SC-70-5/SOT-353)
• Voltage - Supply, Single (V+) 2V ~ 5.5V
• Switch Circuit SPST - NO
• Multiplexer/Demultiplexer Circuit 1:1
• Switch Time (Ton, Toff) (Max) 6ns, 2ns
• Channel Capacitance (CS(off), CD(off)) 4.1pF
• Current - Leakage (IS(off)) (Max) 100nA
• Number of Circuits 1
