Technical Details

• Features Bootstrap Circuit
• Package / Case 40-VFQFN Exposed Pad
• Mounting Type Surface Mount
• Interface SPI
• Operating Temperature -40°C ~ 150°C (TA)
• Output Configuration Half Bridge (2)
• Voltage - Supply 5.5V ~ 50V
• Rds On (Typ) 2.4Ohm LS, 8Ohm HS
• Applications DC Motors, Solenoids
• Technology NMOS
• Voltage - Load 6V ~ 50V
• Supplier Device Package 40-QFN (6x6)
• Fault Protection Current Limiting, Over Temperature, Shoot Through, Short Circuit
• Load Type Inductive, Capacitive, Resistive
