- Product Model TLC5946PWPR
- Brand Texas Instruments
- RoHS Yes
- Description IC LED DRVR LINEAR 40MA 28HTSSOP
- Classification LED Drivers
-
PDF
Technical Details
- Package / Case 28-PowerTSSOP (0.173", 4.40mm Width)
- Voltage - Output 17V
- Mounting Type Surface Mount
- Number of Outputs 16
- Type Linear
- Operating Temperature -40°C ~ 85°C (TA)
- Applications Backlight, Signage
- Current - Output / Channel 40mA
- Internal Switch(s) Yes
- Topology Shift Register
- Supplier Device Package 28-HTSSOP
- Voltage - Supply (Min) 3V
- Voltage - Supply (Max) 5.5V
