Technical Details

• Package / Case 20-WQFN Exposed Pad
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 125°C
• On-State Resistance (Max) 1.5Ohm
• -3db Bandwidth 75MHz
• Supplier Device Package 20-TQFN (5x5)
• Voltage - Supply, Single (V+) 3V ~ 5.5V
• Charge Injection 1720pC
• Crosstalk -103dB @ 100kHz
• Switch Circuit SP4T - NO
• Multiplexer/Demultiplexer Circuit 4:1
• Switch Time (Ton, Toff) (Max) 2ms, 1.5ms
• Channel Capacitance (CS(off), CD(off)) 78pF
• Current - Leakage (IS(off)) (Max) 200nA
• Number of Circuits 2
