Technical Details

• Package / Case 16-SOIC (0.154", 3.90mm Width)
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 85°C (TA)
• On-State Resistance (Max) 85Ohm
• Supplier Device Package 16-SOIC
• Voltage - Supply, Single (V+) 5V ~ 36V
• Voltage - Supply, Dual (V±) ±5V ~ 20V
• Charge Injection -1pC
• Crosstalk -100dB @ 1MHz
• Switch Circuit SPST - NC
• Multiplexer/Demultiplexer Circuit 1:1
• Switch Time (Ton, Toff) (Max) 250ns, 140ns
• Channel Capacitance (CS(off), CD(off)) 4pF, 4pF
• Current - Leakage (IS(off)) (Max) 500pA
• Number of Circuits 4
