Technical Details

• Package / Case TO-252-5, DPAK (4 Leads + Tab), TO-252AD
• Output Type Fixed
• Mounting Type Surface Mount
• Current - Output 500mA
• Operating Temperature -40°C ~ 125°C
• Output Configuration Positive
• Current - Quiescent (Iq) 500 µA
• Voltage - Input (Max) 16V
• Number of Regulators 1
• Supplier Device Package DPAK-5
• Voltage - Output (Min/Fixed) 5V
• Control Features Enable
• Grade Automotive
• PSRR 75dB ~ 70dB (120hZ ~ 10kHz)
• Voltage Dropout (Max) 0.7V @ 500mA
• Protection Features Over Current, Over Temperature, Reverse Polarity
• Current - Supply (Max) 20 mA
• Qualification AEC-Q100
