- Product Model DGD2388MS20-13
- Brand Zetex Semiconductors (Diodes Inc.)
- RoHS Yes
- Description HV Gate Driver SO-20 T&R 1.5K
- Classification Gate Drivers
-
PDF
Inventory:5762
Technical Details
- Package / Case 20-SOIC (0.295", 7.50mm Width)
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 125°C (TA)
- Voltage - Supply 10V ~ 20V
- Input Type Non-Inverting
- High Side Voltage - Max (Bootstrap) 600 V
- Supplier Device Package 20-SO Type TH
- Rise / Fall Time (Typ) 45ns, 25ns
- Channel Type 3-Phase
- Driven Configuration Half-Bridge
- Number of Drivers 6
- Gate Type N-Channel MOSFET
- Logic Voltage - VIL, VIH 0.8V, 2.4V
- Current - Peak Output (Source, Sink) 420mA, 750mA
- Grade Automotive
- Qualification AEC-Q100
