Technical Details

• Package / Case 16-SOIC (0.154", 3.90mm Width)
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 85°C (TA)
• On-State Resistance (Max) 3.5Ohm
• -3db Bandwidth 50MHz
• Supplier Device Package 16-SOIC
• Voltage - Supply, Single (V+) 1.8V ~ 5.5V
• Voltage - Supply, Dual (V±) ±2.5V
• Charge Injection 13pC
• Crosstalk -85dB @ 1MHz
• Multiplexer/Demultiplexer Circuit 8:1
• Channel-to-Channel Matching (ΔRon) 100mOhm
• Switch Time (Ton, Toff) (Max) 18ns, 7ns
• Channel Capacitance (CS(off), CD(off)) 9pF, 40pF
• Current - Leakage (IS(off)) (Max) 250pA
• Number of Circuits 1
