- Product Model MAX4730EXT+T
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC SWITCH SPDT X 1 5.5OHM SC70-6
- Classification Analog Switches, Multiplexers, Demultiplexers
-
PDF
Technical Details
- Package / Case 6-TSSOP, SC-88, SOT-363
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 85°C (TA)
- On-State Resistance (Max) 5.5Ohm
- -3db Bandwidth 300MHz
- Supplier Device Package SC-70-6
- Voltage - Supply, Single (V+) 1.8V ~ 5.5V
- Charge Injection 3pC
- Crosstalk -67dB @ 1MHz
- Switch Circuit SPDT
- Multiplexer/Demultiplexer Circuit 2:1
- Channel-to-Channel Matching (ΔRon) 50mOhm
- Switch Time (Ton, Toff) (Max) 45ns, 26ns
- Channel Capacitance (CS(off), CD(off)) 6.5pF
- Current - Leakage (IS(off)) (Max) 2nA
- Number of Circuits 1
