- Product Model MAX5891EGK+D
- Brand Maxim Integrated / Analog Devices
- RoHS Yes
- Description IC DAC 16BIT A-OUT 68QFN
- Classification Digital to Analog Converters (DAC)
-
PDF
Technical Details
- Package / Case 68-VFQFN Exposed Pad
- Output Type Current - Unbuffered
- Mounting Type Surface Mount
- Number of Bits 16
- Data Interface LVDS - Parallel
- Reference Type External, Internal
- Operating Temperature -40°C ~ 85°C
- Voltage - Supply, Analog 1.71V ~ 1.89V, 3.135V ~ 3.465V
- Voltage - Supply, Digital 1.71V ~ 1.89V, 3.135V ~ 3.465V
- Settling Time 11µs (Typ)
- Supplier Device Package 68-QFN (10x10)
- Architecture Current Steering
- Number of D/A Converters 1
- INL/DNL (LSB) ±3.8, ±2.8
- Differential Output Yes
- DigiKey Programmable Not Verified
