- Product Model TPS1HC30BQPWPRQ1
- Brand Texas Instruments
- RoHS Yes
- Description AUTOMOTIVE, 28-V, 30-M, 5-A, SIN
- Classification Power Distribution Switches, Load Drivers
-
PDF
Technical Details
- Features Auto Restart, Latch Function, Slew Rate Controlled, Status Flag
- Package / Case 14-PowerTSSOP (0.173", 4.40mm Width)
- Output Type N-Channel
- Mounting Type Surface Mount
- Number of Outputs 1
- Interface On/Off
- Switch Type General Purpose
- Operating Temperature -40°C ~ 125°C (TA)
- Output Configuration High Side
- Rds On (Typ) 30mOhm
- Input Type Non-Inverting
- Voltage - Load 2.6V ~ 28V
- Voltage - Supply (Vcc/Vdd) Not Required
- Current - Output (Max) 5A
- Ratio - Input:Output 1:1
- Supplier Device Package 14-HTSSOP
- Fault Protection Current Limiting (Fixed), Over Temperature, Over Load, Reverse Battery, Short Circuit, UVLO
- Grade Automotive
- Qualification AEC-Q100
