- Product Model 2EDL8034G4CXTMA1
- Brand IR (Infineon Technologies)
- RoHS Yes
- Description INT. POWERSTAGE/DRIVER
- Classification Gate Drivers
-
PDF
Inventory:6465
Technical Details
- Package / Case 10-VDFN Exposed Pad
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 125°C (TJ)
- Voltage - Supply 8V ~ 17V
- Input Type Non-Inverting
- High Side Voltage - Max (Bootstrap) 120 V
- Supplier Device Package PG-VDSON-10-2
- Rise / Fall Time (Typ) 4.6ns, 4.4ns
- Channel Type Independent
- Driven Configuration Half-Bridge
- Number of Drivers 2
- Gate Type N-Channel, P-Channel MOSFET
- Current - Peak Output (Source, Sink) 4A, 6A
- DigiKey Programmable Not Verified
