- Product Model LTC3785EUF#PBF
- Brand Linear Technology (Analog Devices, Inc.)
- RoHS Yes
- Description IC REG CTRLR BUCK-BOOST 24QFN
- Classification DC DC Switching Controllers
-
PDF
Technical Details
- Package / Case 24-WFQFN Exposed Pad
- Output Type Transistor Driver
- Mounting Type Surface Mount
- Function Step-Up/Step-Down
- Operating Temperature -40°C ~ 85°C (TA)
- Output Configuration Positive
- Frequency - Switching 100kHz ~ 1MHz
- Topology Buck-Boost
- Voltage - Supply (Vcc/Vdd) 2.7V ~ 10V
- Supplier Device Package 24-QFN (4x4)
- Synchronous Rectifier Yes
- Control Features Current Limit, Enable, Soft Start
- Output Phases 1
- Duty Cycle (Max) 99%
- Clock Sync No
- Number of Outputs 2
