- Product Model 6ED2742S01QXTMA1
- Brand IR (Infineon Technologies)
- RoHS Yes
- Description THREE-PHASE MOTOR CONTROL GATE D
- Classification Gate Drivers
-
PDF
Inventory:3598
Technical Details
- Package / Case 32-PowerVFQFN
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 125°C (TA)
- Voltage - Supply 6V ~ 140V
- Input Type Non-Inverting
- High Side Voltage - Max (Bootstrap) 160 V
- Supplier Device Package 32-VQFN (5x5)
- Rise / Fall Time (Typ) 20ns, 10ns
- Channel Type 3-Phase
- Driven Configuration Half-Bridge
- Number of Drivers 6
- Gate Type N-Channel MOSFET
- Logic Voltage - VIL, VIH 1.4V, 1.4V
- Current - Peak Output (Source, Sink) 1A, 2A
- DigiKey Programmable Not Verified
