- Product Model LM51521QRGRRQ1
- Brand Texas Instruments
- RoHS Yes
- Description AUTOMOTIVE 2.2 MHZ WIDE VIN LOW
- Classification DC DC Switching Controllers
-
PDF
Technical Details
- Package / Case 20-VFQFN Exposed Pad
- Output Type Transistor Driver
- Mounting Type Surface Mount, Wettable Flank
- Function Step-Up
- Operating Temperature -40°C ~ 150°C (TJ)
- Output Configuration Positive
- Frequency - Switching 100kHz ~ 2.2MHz
- Topology Boost
- Voltage - Supply (Vcc/Vdd) 0.8V ~ 42V
- Supplier Device Package 20-VQFN (3.5x3.5)
- Synchronous Rectifier Yes
- Control Features Dead Time Control, Enable, Frequency Control, Ramp, Soft Start, Tracking
- Output Phases 1
- Duty Cycle (Max) 80%, 94%
- Clock Sync Yes
- Grade Automotive
- Number of Outputs 1
- Qualification AEC-Q100
