Technical Details

• Package / Case SC-74A, SOT-753
• Mounting Type Surface Mount
• Logic Type NAND Gate
• Operating Temperature -55°C ~ 125°C
• Voltage - Supply 1.65V ~ 5.5V
• Current - Output High, Low 32mA, 32mA
• Number of Inputs 2
• Supplier Device Package SOT-23-5
• Input Logic Level - High 1.7V ~ 2V
• Input Logic Level - Low 0.7V ~ 0.8V
• Max Propagation Delay @ V, Max CL 5ns @ 5V, 50pF
• Number of Circuits 1
• Current - Quiescent (Max) 10 µA
