- Product Model L9825
- Brand STMicroelectronics
- RoHS Yes
- Description IC PWR DRIVER N-CHAN 1:8 PWRSO20
- Classification Power Distribution Switches, Load Drivers
-
PDF
Technical Details
- Features Status Flag
- Package / Case 20-SOIC (0.433", 11.00mm Width) Exposed Pad
- Output Type N-Channel
- Mounting Type Surface Mount
- Number of Outputs 8
- Interface SPI
- Switch Type Latched Driver
- Operating Temperature -40°C ~ 150°C (TJ)
- Output Configuration Low Side
- Rds On (Typ) 750mOhm (Max)
- Voltage - Load 45V (Max)
- Voltage - Supply (Vcc/Vdd) 4.5V ~ 5.5V
- Current - Output (Max) 1A
- Ratio - Input:Output 1:8
- Supplier Device Package PowerSO-20
- Fault Protection Current Limiting (Fixed), Over Temperature
