- Product Model DRV8231ADSGR
- Brand Texas Instruments
- RoHS Yes
- Description 33V H BRIDGE MOTOR DRIVER WITH C
- Classification Motor Drivers, Controllers
-
PDF
Technical Details
- Package / Case 8-WFDFN Exposed Pad
- Mounting Type Surface Mount
- Function Driver - Fully Integrated, Control and Power Stage
- Current - Output 3.7A
- Interface PWM
- Operating Temperature -40°C ~ 125°C (TA)
- Output Configuration Half Bridge (2)
- Voltage - Supply 4.5V ~ 33V
- Applications Printer
- Technology NMOS
- Voltage - Load 4.5V ~ 33V
- Supplier Device Package 8-WSON (2x2)
- Motor Type - Stepper Bipolar
- Motor Type - AC, DC Brushed DC
