Technical Details

• Package / Case 8-SOIC (0.154", 3.90mm Width)
• Mounting Type Surface Mount
• Operating Temperature -40°C ~ 85°C (TA)
• On-State Resistance (Max) 35Ohm
• Supplier Device Package 8-SOIC
• Voltage - Supply, Dual (V±) ±2.7V ~ 8V
• Charge Injection 2pC
• Crosstalk -85dB @ 1MHz
• Switch Circuit SPST - NO
• Multiplexer/Demultiplexer Circuit 1:1
• Channel-to-Channel Matching (ΔRon) 300mOhm
• Switch Time (Ton, Toff) (Max) 150ns, 100ns
• Channel Capacitance (CS(off), CD(off)) 9pF, 9pF
• Current - Leakage (IS(off)) (Max) 100pA
• Number of Circuits 2
