Technical Details

• Package / Case 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
• Output Type TTL
• Mounting Type Surface Mount
• Number of Elements 2
• Type General Purpose
• Operating Temperature -40°C ~ 85°C
• Voltage - Supply, Single/Dual (±) 4.5V ~ 5.5V
• Supplier Device Package 8-uMAX/uSOP
• Propagation Delay (Max) 9ns
• Current - Quiescent (Max) 4.2mA
• Voltage - Input Offset (Max) 3mV @ 5.5V
• Current - Input Bias (Max) 0.5µA @ 5V
• Current - Output (Typ) 40mA
• CMRR, PSRR (Typ) 95dB CMRR, 82dB PSRR
