Technical Details

• Package / Case SOT-23-5 Thin, TSOT-23-5
• Mounting Type Surface Mount
• Logic Type NAND Gate
• Operating Temperature -55°C ~ 125°C
• Voltage - Supply 2V ~ 5.5V
• Current - Output High, Low 8mA, 8mA
• Number of Inputs 2
• Supplier Device Package 5-TSOP
• Input Logic Level - High 1.5V ~ 3.85V
• Input Logic Level - Low 0.5V ~ 1.65V
• Max Propagation Delay @ V, Max CL 7.5ns @ 5V, 50pF
• Number of Circuits 1
• Current - Quiescent (Max) 1 µA
