- Product Model TPS274160ARLHR
- Brand Texas Instruments
- RoHS Yes
- Description 40-V, 160-M, 4-CHANNEL SMART HIG
- Classification Power Distribution Switches, Load Drivers
-
PDF
Technical Details
- Package / Case 28-WFQFN Exposed Pad
- Output Type N-Channel
- Mounting Type Surface Mount
- Number of Outputs 4
- Interface On/Off
- Switch Type General Purpose
- Operating Temperature -40°C ~ 125°C (TJ)
- Output Configuration High Side
- Rds On (Typ) 160mOhm
- Input Type Non-Inverting
- Voltage - Load 5V ~ 36V
- Voltage - Supply (Vcc/Vdd) Not Required
- Current - Output (Max) 1.35A
- Ratio - Input:Output 1:1
- Supplier Device Package 28-WQFN (4x5)
- Fault Protection Current Limiting (Adjustable), Over Temperature, Short Circuit, UVLO
