Technical Details

• Package / Case 10-WFDFN Exposed Pad
• Output Type Fixed
• Mounting Type Surface Mount
• Current - Output 500mA, 500mA
• Operating Temperature -40°C ~ 125°C (TJ)
• Output Configuration Positive
• Current - Quiescent (Iq) 35 µA
• Voltage - Input (Max) 6V
• Number of Regulators 2
• Supplier Device Package 10-WSON (2x2)
• Voltage - Output (Min/Fixed) 1.8V, 3.3V
• Control Features Enable
• PSRR 50dB ~ 30dB (1kHz ~ 1MHz)
• Voltage Dropout (Max) 0.19V @ 500mA, 0.13V @ 500mA
• Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
