- Product Model DAC80501ZDGSR
- Brand Texas Instruments
- RoHS Yes
- Description SINGLE CHANNEL DAC 16BIT
- Classification Digital to Analog Converters (DAC)
-
PDF
Technical Details
- Package / Case 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Output Type Voltage - Buffered
- Mounting Type Surface Mount
- Number of Bits 16
- Data Interface I2C, SPI
- Reference Type External, Internal
- Operating Temperature -40°C ~ 125°C
- Voltage - Supply, Analog 2.7V ~ 5.5V
- Voltage - Supply, Digital 2.7V ~ 5.5V
- Settling Time 5µs (Typ)
- Supplier Device Package 10-VSSOP
- Architecture R-2R
- Number of D/A Converters 1
- INL/DNL (LSB) ±1 (Max), ±1 (Max)
- Differential Output No
- DigiKey Programmable Not Verified
