- Product Model SG2525AP
- Brand STMicroelectronics
- RoHS Yes
- Description IC REG CTRLR BCK/PSH-PULL 16SOIC
- Classification DC DC Switching Controllers
-
PDF
Technical Details
- Package / Case 16-SOIC (0.154", 3.90mm Width)
- Output Type Transistor Driver
- Mounting Type Surface Mount
- Function Step-Down, Step-Up/Step-Down
- Operating Temperature -25°C ~ 85°C (TA)
- Output Configuration Positive
- Frequency - Switching 100Hz ~ 400kHz
- Topology Buck, Push-Pull
- Voltage - Supply (Vcc/Vdd) 8V ~ 35V
- Supplier Device Package 16-SO
- Synchronous Rectifier Yes
- Control Features Enable, Soft Start
- Output Phases 1
- Duty Cycle (Max) 49%
- Clock Sync Yes
- Number of Outputs 2
