- Product Model UCC27282DRCR
- Brand Texas Instruments
- RoHS Yes
- Description IC GATE DRVR HALF-BRIDGE 10VSON
- Classification Gate Drivers
Technical Details
- Package / Case 10-VFDFN Exposed Pad
- Mounting Type Surface Mount
- Operating Temperature -40°C ~ 125°C
- Voltage - Supply 5.5V ~ 16V
- Input Type Non-Inverting
- High Side Voltage - Max (Bootstrap) 120 V
- Supplier Device Package 10-VSON (3x3)
- Rise / Fall Time (Typ) 12ns, 10ns
- Channel Type Independent
- Driven Configuration Half-Bridge
- Number of Drivers 2
- Gate Type N-Channel MOSFET
- Logic Voltage - VIL, VIH 0.9V, 2.4V
- Current - Peak Output (Source, Sink) 2.5A, 3.5A
- DigiKey Programmable Not Verified
